Available in diameters from #10 to 3/8" and lengths from 1" to 3".
Nominal Size |
E |
A |
H |
O |
P |
|||||
Body Diameter |
Head Diameter |
Head Height |
Square Width |
Square Depth |
||||||
MAX |
MIN |
MAX |
MIN |
MAX |
MIN |
MAX |
MIN |
MAX |
MIN |
|
10 |
0.199 |
0.182 |
0.656 |
0.625 |
0.114 |
0.094 |
0.199 |
0.185 |
0.125 |
0.094 |
1/4 |
0.260 |
0.237 |
0.844 |
0.813 |
0.145 |
0.125 |
0.26 |
0.245 |
0.156 |
0.125 |
5/16 |
0.324 |
0.298 |
1.031 |
1.000 |
0.176 |
0.156 |
0.324 |
0.307 |
0.187 |
0.156 |
3/8 |
0.388 |
0.360 |
1.219 |
1.188 |
0.208 |
0.188 |
0.388 |
0.368 |
0.219 |
0.188 |
